3 in 1 Oxygen Analyzer For PSA Oxygen Machine Monitor and Service

Brand: AERTI

Product origin: Shenyang, China

Delivery time: 7-30 days depend on different quantity

Supply capacity: 10000 Sets/Month

1.The Small Palm Oxygen Analyzer adopt ultrasonic principle and long service life
2.The Small Palm Oxygen Analyzer is a accurate oxygen measurements
3.The Small Palm Oxygen Analyzer is convenient to measure outlet pressure in kPa, bar or PSI
4.The Small Palm Oxygen Analyzer has reinforced sample gas inlet port
5.The Small Palm Oxygen Analyzer adopt durable and compact design, easy to clean, Easy operate and easy calibration

3 in 1 Oxygen Analyzer For PSA Oxygen Machine Monitor and Service

MCI-1 oxygen analyzer (oxygen meter) is small and light, which can test the PSA oxygen concentrator's purity, pressure and flow. It is a very good tool for PSA oxygen concentrator service.

o2 analyzer


  The Portable Oxygen Analyzer is an measurement instrument developed by SHENYANG AERTI TECH CO.,LTD for PSA oxygen concentrator. It is designed to measure oxygen concentration, flow and outlet pressure of oxygen concentrators. The Portable Medical Use Oxygen Gas Purity Analyzer is fast, accurate, and highly accurate, and it uses advanced sensors to measure oxygen levels. It is the first 3-in-1 oxygen analyzer in China. It adopts electrochemical sensor that with high sensitivity and long using life.



Specifications of the Portable Medical Use Oxygen Gas Purity Analyzer

Measurement
Item

Measurement
Range

Measurement
Resolution

Measurement
Accuracy

Power
Supply

Net
Weight

Gross
Weight

Size

Oxygen Purity

30%-96%

0.10%

±3%

One 9V
Battery

115g

670g

145x66x48
(mm)

Flow

1-10L/min

0.1L/min

±0.2L/min(1-2L)

±0.3L/min(2-10L)

Pressure

0-3bar

1 kPa

±2%FS

0.1bar

0.1psi


Product Features of Portable Oxygen Analyzer:

  • Portable hand-held design, one-hand operation, light weight and easy to carry, convenient and quick, suitable for production field testing;

  • With 3 minutes automatic shutdown function, reduce energy consumption;

  • Using imported components from world-renowned brands, the performance is stable and reliable;

  • The built-in electrochemical sensor can accurately measure output gas at the outlet of a medical molecular sieve oxygen concentrator (oxygen purity, flow and pressure). The sensor adopts imported parts from world-renowned brands, with ultra-high test accuracy, ultra-low failure rate and ultra-long service life.

  • The Palm Oxygen Analyzer is a accurate oxygen measurements

  • The Palm Oxygen Analyzer is convenient to measure outlet pressure in kPa, bar or PSI

  • The Palm Oxygen Analyzer adopt durable and compact design, easy to clean, Easy operate and easy calibration

  • The Palm Oxygen Analyzer has reinforced sample gas inlet port

  • The Palm Oxygen Analyzer adopt ultrasound principle and long service life

Oxygen Analyser

Portable Oxygen Analyzer

o2 analyzer

Intended use:

  • MCI-1 is for use only by trained personnel.

  • MCI-1 Oxygen Analyzer is intended to be used in an environment where oxygen concentrators are being serviced or repaired.

  • MCI-1 Oxygen Analyzer is not intended to be used by patients who are prescribed oxygen, nor is it intended to continuously monitor or confirm oxygen delivery to a patient.


Oxygen Analyser

Portable Oxygen Analyzer


Company Profile

o2 analyzer

Oxygen Analyser

FAQ:

  • Which port do you choose?

    Dalian Sea Port, Beijing Air Port, or chosen by customer.

  • What payment terms are acceptable?

    T/T ,  L/C at sight, Western Union

  • What's our delivery time?

    Usually within 7 working days after receipt of T/T Payment. It depends on the order quantity.

  • What's our MOQ?

    Our MOQ is 1 carton.
